Product Specifications

Working Load Limits:

• 3000KG with Height Extension according to AS2615:2016
• 2000KG without Height Extension

Height and Weight Specifications:

• Height Lowered – 155mm
• Height Raised (No Extension) – 550mm
• Height Raised (With Extension) – 700mm
• Weight: 36kg

Product Size:

• 81cm Long x 33cm Wide x 27cm Tall
• Height can be reduced to 21cm if lever shoulder is pushed down.
• PACKAGE SIZE – 88cmx40cmx31cm

✅ Industry-Leading Lift Height 700mm maximum reach with extension included → Perfect for lifted 4WDs and high-clearance vehicles

✅ 3 Tonne (3000kg) Capacity Handles fully-loaded dual-cabs, American trucks, and commercial vehicles → No job too heavy

✅ True All-Terrain Performance

• Solid nylon wheels crush obstacles (sticks, bolts, kerbs, grass)
• Full-length steel skid plate prevents sinking in sand, mud, gravel → Works where standard jacks fail

✅ Lever Lock Positioning System Foot-activated pivot lets you move the jack side-to-side effortlessly → Perfect positioning on uneven surfaces

✅ Rapid 7-Pump Lift Double-pump hydraulics get you from ground to full height fast → Less time jacking, more time working

✅ Balanced Carry Handle Integrated handle at optimal balance point → Easy one-hand carry despite 36kg weight

✅ Commercial-Grade Construction

• 12mm aluminium side plates
• Stainless steel hardware
• Solid steel axles and lift arm → Built for decades of hard use

🔧 Mounting Options Available Secure brackets sold separately – mount in your vehicle for instant access

Who Uses The Titan Jack?

4WDers & Offroaders – The only jack you would use at home and take on a trip

Mechanics & Workshops – Workshop-grade quality, available spare parts, and 2 Year Warranty included. Low enough for a normal sedan, tall enough for a lifted 4×4

Mines & Fleet – Save time and guarantee safety, ensure your work is done right with the stable height and high capacity

Tradies – We’ve seen our jacks used all over, from lifting up mini-excavators to propping up formwork

Farmers – The best jack you can use for every terrain

When You Need It Most

Broken CV? Flat Tire? Stuck in some Bog? The standard Bottle Jack doesn’t reach?

Never use another floor jack again. Use a Titan Terrain Rugged Floor Jack.
